    Building Materials Flammability Tester Touch Screen Steel - Structure Fireproof Coating Sample Test Furnace

    Ask Lasest Price
    Brand Name : SKYLINE
    Model Number : GJL-2
    Certification : CE
    Price : negotiated
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1 unit/ month
    Delivery Time : 10 work days
    • Product Details
    • Company Profile

    Building Materials Flammability Tester Touch Screen Steel - Structure Fireproof Coating Sample Test Furnace

    Steel-Structure Fireproof Coating Sample Test Furnace High Accuracy 3KW

    Technical indicators

    Operating VoltageAC 380V +/-10% 50Hz ; Electric power: 3KW
    Stove Pressure Measurement Range0-100Pa Measurement Accuracy: ≤ +/-3Pa
    Air Flow0-50 m³/min Measurement Accuracy: ≤ +/-0.5 m³/min
    Burning AirflowPropane ,Liquefied gas
    Gas Flow0-100 L/min;Measurement Accuracy:2.5 level
    Tank Capacity50 kg*2
    Test TemperatureProgram warming:60min room temperature-925℃;120min room temperature-1050℃;180min room temperature-1115℃;240min room temperature-1150℃;300min room temperature-1180℃; 360min room temperature-1210℃;
    Equipment Precisiona.furnace temperature: +/-15℃;b.internal specimen temperature: +/-10℃; c.backfire specimen temperature: +/-4℃
    Temperature Sensora.armored platinum rhodium platinum value S thermocouple
    accuracy class:II level;b.armored nickel-chromium nickel-silicon value K thermocouple
    accuracy class:II level
    Timing Range0-360 min;Timing Accuracy: < +/-2s
    Maximum of Burning Length of the Sample1600mm
    Instrument DimensionsTest plate bracket 670mm*670mm*1100mm;Control box 800mm*500mm*500mm

    Features
    1.PLC+NA view professional software, touch screen control, easy operation
    2. The whole process of testing is fully automated
    3. Temperature errors are lower than the national standard


    Design Standards
    GB14907-2002 Steel-Structure Fireproof Coating
    GB T9978-2008 Fire Resistance Test Method for Building Components
    GB T23864-2009 Plugging Material of Fireproof
